MODEL

Axpert VM II   Premium 1.2K

Axpert VM II   Premium 2.5K

Axpert VM II

Premium 3K-24V

Axpert VM II

Premium 3K-48V

Axpert VM II

Premium 5K

Rated Power

1200VA/1200W

2500VA/2500W

3000VA/3000W

3000VA/3000W

5000VA/5000W

INPUT

Voltage

230 VAC

Selectable Voltage Range

170-280 VAC (For Personal Computers) ;

90-280 VAC (For Home Appliances)

Frequency Range

50 Hz/60 Hz (Auto sensing)

OUTPUT

AC Voltage Regulation (Batt. Mode)

230VAC ± 5%

Surge Power

2400VA

5000VA

6000VA

6000VA

10000VA

Efficiency (Peak)

93%

Transfer Time

10 ms  (For Personal Computers) ;

20 ms (For Home Appliances)

Waveform

Pure sine wave

BATTERY

Battery Voltage

12 VDC

24 VDC

48 VDC

Floating Charge Voltage

13.5 VDC

27 VDC

54 VDC

Overcharge Protection

16 VDC

32 VDC

63 VDC

SOLAR CHARGER & AC CHARGER

Solar Charger Type

MPPT

Maximum PV Array Open Circuit Voltage

350 VDC

450 VDC

500 VDC

Maximum PV Array Power

2000W

3000W

5000W

Maximum PV Input Current

13A

18A

MPP Range @ Operating Voltage

60 ~ 300 VDC

60 ~ 400 VDC

120 ~ 450VDC

Maximum Solar Charge Current

100 A

100A

Maximum AC Charge Current

80A

60A

100A

Maximum Charge Current

100A

100A

PHYSICAL

Dimension, D x W x H (mm)

90 x 288 x 357

110 x 288 x 390

90 x 288 x 357

120 x 300 x 440

Net Weight (kgs)

6.5

7.0

7.2

7.0

10

Communication Interface

RS232/RS485, optional WiFi

ENVIRONMENT

Humidity

5% to 95% Relative Humidity (Non-condensing)

Operating Temperature

-10°C to 50°C

Storage Temperature

-15°C to 60°C
