GTO-IS E 5.5kw Features 2 enhanced MPPT chargers，the flexible smart hybrid inverter can utilize solar, AC and battery power without interrupting the power supply

Features 2 enhanced MPPT chargers

The quota output power is 5.5KW. Equipped with 2 enhanced MPPT chargers, the maximum AC/ solar charging current can reach 60A. It has an application-based programmable mode of operation that starts with self-consumption, grid feed or automatic hybrid operation. The flexible smart hybrid inverter can utilize solar, AC and battery power without interrupting the power supply.
Product Features

• Pure sine wave output

• Self-consumption and Feed-in to the grid

• Programmable supply priority for PV, Battery or Grid

• User-adjustable battery charging current suits different types of batteries

• Programmable multiple operation modes: grid-tie, off-grid and grid-tie with backup

• Built-in timer for various mode of on/off operation

• Built-in 2 strings of MPP trackers

• Built-in 60A AC/Solar charger

• Optional DC switch

MODEL	InfiniSolar E 5.5kw
MAXIMUM PV INPUT POWER	6500W
RATED OUTPUT POWER	5500W
MAXIMUM CHARGING POWER	2880 W
GRID-TIE OPERATION
PV INPUT (DC)
Nominal DC Voltage / Maximum DC Voltage	360 VDC / 500 VDC
Start-up Voltage / Initial Feeding Voltage	116 VDC / 150 VDC
MPP Voltage Range	120 VDC ~ 450 VDC
Number of MPP Trackers / Maximum Input Current	2 / 2 x 13 A
GRID OUTPUT (AC)
Nominal Output Voltage	202/208/220/230/240 VAC
Output Voltage Range	184 - 264.5 VAC*
Max. Output Current	23.9A*
Power Factor	> 0.99
EFFICIENCY
Maximum Conversion Efficiency (DC/AC)	96%
European Efficiency@ Vnominal	95%
OFF-GRID OPERATION
AC INPUT
AC Start-up Voltage / Auto Restart Voltage	120 - 140 VAC / 180 VAC
Acceptable Input Voltage Range	170 -280 VAC
Maximum AC Input Current	40 A
PV INPUT (DC)
Maximum DC Voltage	500 VDC
MPP Voltage Range	120 VDC ~ 450 VDC
Number of MPP Trackers / Maximum Input Current	2 / 2 x 13 A
BATTERY MODE OUTPUT (AC)
Nominal Output Voltage	202/208/220/230/240 VAC
Output Waveform	Pure sinewave
Efficiency (DC to AC)	93%
HYBRID OPERATION
PV INPUT (DC)
Nominal DC Voltage / Maximum DC Voltage	360 VDC / 500 VDC
Start-up Voltage / Initial Feeding Voltage	116 VDC / 150 VDC
MPP Voltage Range	120 VDC ~ 450 VDC
Number of MPP Trackers / Maximum Input Current	2 / 2 x 13 A
GRID INPUT
Nominal Output Voltage	202/208/220/230/240 VAC
Output Voltage Range	184 - 264.5 VAC*
Max. Output Current	23.9A*
AC INPUT
AC Start-up Voltage / Auto Restart Voltage	120 - 140 VAC / 180 VAC
Acceptable Input Voltage Range	170 -280 VAC
Maximum AC Input Current	40A
BATTERY MODE OUTPUT (AC)
Nominal Output Voltage	202/208/220/230/240 VAC
Efficiency (DC to AC)	93%
BATTERY & CHARGER
Nominal DC Voltage	48 VDC
Maximum Solar Charge Current	60 A
GENERAL
PHYSICAL
Dimension, D x W x H (mm)	110 x 450 x 445
Net Weight (kgs)	16
INTERFACE
External Safety Box (Optional)	RS-232/USB
Communication ports	Optional SNMP, Modbus and AS-400 cards
ENVIRONMENT
Humidity	0 ~ 90% RH (Non-condensing)
Operating Temperature	0 to 40ºC
Altitude	0 ~ 1000 m**
