GTO-IS V4 TWIN 6kw Dual output hybrid inverter

The RGB lighting effect of the self-setting LED lamp ring shows different operating states

The IS V4 TWIN IS the third generation upgrade of our IS V series. Equipped with a 4.3-inch color LCD, touch buttons and a self-configurable LCD light ring, RGB lighting effects show different operating states and can accept high PV voltage ranges, which can simplify the installation of photovoltaic systems. In addition, the battery independent function keeps the inverter running regardless of whether the battery is connected. The inverter also provides parallel functions for up to nine machines, providing a high degree of flexibility and operating space for future power expansion.
Product Features

• Maximum PV input current 27A

• Dual outputs for smart load management

• Touchable button with 4.3" colored LCD

• Built-in WiFi for mobile monitoring (APP is available)

• Programmable supply priority for PV, Battery or Grid

• User-adjustable charging current and voltage

• Programmable multiple operation modes: Grid-tie, off-grid and grid-tie with backup

• Reserved communication port for BMS

• Parallel operation up to 9 units

MODEL	InfiniSolar V 4 TWIN 6kw
PHASE	1-phase in / 1-phase out
MAXIMUM PV INPUT POWER	7000W
RATED OUTPUT POWER	6000W
MAXIMUM CHARGING POWER	6000W
GRID-TIE OPERATION
PV INPUT (DC)
Nominal DC Voltage / Maximum DC Voltage	360 VDC / 500 VDC
Start-up Voltage / Initial Feeding Voltage	120VDC / 150 VDC
MPP Voltage Range	120 VDC ~ 430 VDC
Number of MPP Trackers / Maximum Input Current	1 / 27A
GRID OUTPUT (AC)
Nominal Output Voltage	220/230/240 VAC
Output Voltage Range	184 - 264.5 VAC or 195.5 - 253 VAC (Selectable)
Nominal Output Current	26A
Power Factor	> 0.99
EFFICIENCY
Maximum Conversion Efficiency (DC/AC)	96%
OFF-GRID OPERATION
AC INPUT
AC Start-up Voltage / Auto Restart Voltage	120 - 140 VAC / 180 VAC
Acceptable Input Voltage Range	90 - 280 VAC or 170 - 280 VAC
Maximum AC Input Current	40 A
PV INPUT (DC)
Maximum DC Voltage	500 VDC
MPP Voltage Range	120 VDC ~ 430 VDC
Number of MPP Trackers / Maximum Input Current	1 / 27 A
BATTERY MODE OUTPUT (AC)
Nominal Output Voltage	220/230/240 VAC
Output Waveform	Pure sinewave
Efficiency (DC to AC)	93%
HYBRID OPERATION
PV INPUT (DC)
Nominal DC Voltage / Maximum DC Voltage	360 VDC / 500 VDC
Start-up Voltage / Initial Feeding Voltage	120VDC / 150 VDC
MPP Voltage Range	120 VDC ~ 430 VDC
Number of MPP Trackers / Maximum Input Current	1 / 27A
GRID OUTPUT (AC)
Nominal Output Voltage	220/230/240 VAC
Output Voltage Range	184 - 264.5 VAC or 195.5 - 253 VAC (Selectable)
Nominal Output Current	26A
AC INPUT
AC Start-up Voltage / Auto Restart Voltage	120 - 140 VAC / 180 VAC
Acceptable Input Voltage Range	90 - 280 VAC or 170 - 280 VAC
Maximum AC Input Current	40A
BATTERY MODE OUTPUT (AC)
Nominal Output Voltage	220/230/240 VAC
Efficiency (DC to AC)	93%
BATTERY & CHARGER
Nominal DC Voltage	48 VDC
Maximum Solar Charging Current	120A
Maximum AC Charging Current	120A
Maximum Charging Current	120A
GENERAL
PHYSICAL
Dimension, D x W x H (mm)	140 x 295 x 468
Net Weight (kgs)	12
INTERFACE
Parallel Function	Yes, 9 units
Communication Port	USB/RS232/RS485/Wifi/Dry-contact
ENVIRONMENT
Humidity	0 ~ 90% RH (Non-condensing)
Operating Temperature	-10 to 50ºC
