GTO-IS WP LV 6kw IP65 protection rating suitable for indoor and harsh outdoor environments

Support split or single-phase IP65 hybrid inverters

With the IP65 protection rating -IS WP LV 6KW provides comprehensive protection against dust, airborne particles and water jets, making it suitable for indoor and harsh outdoor environments. It supports multiple inputs and outputs: split phase 208/240VAC or single phase 230VAC. The IS WP LV also offers a second terminal for the user to choose from as a generator input or a programmable output.
Product Features

• IP65 waterproof and dustproof for various working conditions

• Support multiple input & output- Split Phase 208/240Vac or Single Phase 230Vac

• Built-in AC coupled function

• Built-in WiFi for mobile monitoring (APP is available)

• Accepts second input power source, generator input compatible

• Optional external CT sensor to guarantee 100% self-consumption

• Built-in communication port for BMS (RS485)

• User-adjustable charging current and voltage

• Parallel operation up to 6 units

MODEL	InfiniSolar WP LV 6kw
Phase	120/240V Split phase, 120V/208V Split phase
Maximum PV Input Power	7500W
Rated Output Power	6000VA/6000W
Maximum Charging Power	6000W
GRID-TIE OPERATION
PV INPUT (DC)
Maximum DC Voltage	600 VDC
Start-up Voltage / Initial Feeding Voltage	125 VDC / 160 VDC
MPP Voltage Range	120 VDC ~ 550 VDC
Number of MPP Trackers / Maximum Input Current	2 / 15A
GRID OUTPUT (AC)
Nominal Output Voltage	120 VAC (P-N), 208 VAC (P-P), 240 VAC (P-P)
Output Voltage Range	105.5 VAC - 132 VAC (per phase)
Nominal Output Current	25 A per phase
Power Factor	0.9 lag to 0.9 lead
EFFICIENCY
Maximum Conversion Efficiency (DC/AC)	96%
OFF-GRID OPERATION
AC INPUT
AC Start-up Voltage / Auto Restart Voltage	85 VAC (per phase) / 90 VAC (per phase)
Acceptable Input Voltage Range	85 - 140 VAC (per phase)
Frequency Range	50 Hz/60 Hz (Auto sensing)
Maximum AC Input Current	40A per phase
PV INPUT (DC)
Maximum DC Voltage	600 VDC
MPP Voltage Range	120 VDC ~ 550 VDC
Number of MPP Trackers / Maximum Input Current	2 / 15A
BATTERY MODE OUTPUT (AC)
Nominal Output Voltage	120 VAC (P-N), 208 VAC (P-P), 240 VAC (P-P)
Output Waveform	Pure sine wave
Efficiency (DC to AC)	91%
HYBRID OPERATION
PV INPUT (DC)
Maximum DC Voltage	600 VDC
Start-up Voltage / Initial Feeding Voltage	125 VDC / 160 VDC
MPP Voltage Range	120 VDC ~ 550 VDC
Number of MPP Trackers / Maximum Input Current	2 / 15A
GRID OUTPUT (AC)
Nominal Output Voltage	120 VAC (P-N), 208 VAC (P-P), 240 VAC (P-P)
Output Voltage Range	105.5 VAC - 132 VAC (per phase)
Nominal Output Current	25A per phase
AC INPUT
AC Start-up Voltage / Auto Restart Voltage	85 VAC (per phase) / 90 VAC (per phase)
Acceptable Input Voltage Range	85 - 140 VAC (per phase)
Maximum AC Input Current	40 A per phase
BATTERY MODE OUTPUT (AC)
Nominal Output Voltage	120 VAC (P-N), 208 VAC (P-P), 240 VAC (P-P)
Efficiency (DC to AC)	91%
BATTERY & CHARGER
Nominal DC Voltage	40-62 VDC
Maximum Solar Charging Current	120 A
Maximum AC Charging Current	120 A
Maximum Charging Current	120 A
GENERAL
PHYSICAL
Dimension, D x W x H (mm)	215.5 x 515 x 700
Net Weight (kgs)	41
INTERACE
Parallel Function	Yes, 6 units
Communication Port	RS232, RS485, WI-FI, USB
ENVIRONMENT
Protection Degree	IP 65
Operating Temperature	-25°C to 60°C (>45°Cderating)
